Tungsten Carbide Cutting Tools

Tungsten Solid Carbide End Mill Cutting Tools

  • Description


1. Product description:

Grade to choose

1. KMG302/KMG303/KMG405/KDG303/KRG102/KTG202

2. YK10F/YK20F/YK30F/YK40F

3. Cutting method : climbing milling

4.  applies to cutting 50~68HRC material


classify end mill:


1.according to the machining application:  the CNC solid carbide end mill can be classify into: High-performance general milling (PM series end mill), General milling(GM series end mill ), machining high hardness steel (HM series end mill ) , Mchining Aluminum (AL series end mill ) and Machining of hard-to-cut material(SM series end mill ).

2.according to the shape: the CNC solid carbide end mill can be classify into: flattened, ball noce, long neck,corrugated edge,radius and some other type end mill. for pictures, please contact Miss Bigel Wu (contact information at below)


3. according to the flutes: 2 flutes end mill, 3 flutes carbide end mill. 4 flutes solid carbide endmill. and 6 flutes end mills.



Grade and appliacation




Product Name

HRC60 solid tungsten carbide flat end mill
Features Variable helix angle and unequal flute spacing
Processing TypeMetal
Precisionwithin 0 ~-0.01mm
Suitable ForStainless Steel, Alloy steel, Die steel, Pre-hardened Steel, Inconel
Machine TypeCNC Milling Machine
Specificationaccording to different items
TRS Min(N/MM²)4000-4200


1, Soon after the order is confirmed, carbide forging die products will start to prepare the RTP powder as per customer’s requirement with our wet-grinding machine

2, Before mass production, we need to do a trial pressing and sintering using every mould, and we check the appearances and the sizes of carbide forging die samples with micrometer, projectors etc. to ensure that the requirements of the drawings can be met before batch production

3,  Bulk production ,press the raw materials to shape blanks,and all carbide forging die blanks must be passed by semi finished inspection,

4, Then sinter blanks to finish (HIP) and finished products inspection, we have 10 sets of vacuum sintering furnace and 2 sets of HIP in the factory ensure the best quality and production capacity.


5, 1). cleaning/tumbling is to make the carbide forging die look more beautiful.
     2).The carbide forging die can be ground according to customers’ order to a tolerance of +/-0.05
